Auto Foam Sealing Machine

52033C.203
52033C.203

Vehicle Specifications

Brand
KAIWEI
Equipment No
KW-530C
Gasket width
5-30 mm
Operating controller
integrated
Effective working range
2300x1250x200 mm (X*Y*Z)
Raw Material
PU (component A+B+C)
Equipment Overall Space
4000X3300X2300 mm(L*W*H)
Color

530C

Effective gluing stroke is 2400 * 1450 * 200mm. It adopts an integrated welding frame. Operation interface uses an integrated console which can rotate 0-90°, no need to remove the electrical wire in the transportation and commissioning. It has 3 raw material tanks and a 3-component mixing head, which can meet the needs of different products using different glues and avoid the trouble of replacing raw materials. The standard machine is equipped with a wireless handheld controller which makes the operation easier. The raw material tanks adopt an integrated design, no need to dismantle the pipe and wire in the transportation and commissioning, so as to avoid glue leakage and polluting the equipment and environment. The max. speed of plane processing is 12m / min.
