Auto Foam Sealing Machine

520D
520D

Vehicle Specifications

Brand
KAIWEI
Equipment No
KW-520D
Gasket width
5-30 mm
Operating controller
independent
Effective working range
2300x1250x200 mm (X*Y*Z)
Raw Material
PU (component A+B)
Equipment Overall Space
4000X3300X2300 mm(L*W*H)
Color




Effective gluing stroke is 2300 * 1250 * 200mm. Operation console is independent and movable. The standard machine is equipped with a handheld controller. The raw material tanks adopt an integrated design, no need to dismantle the pipe and wire in the transportation and commissioning, so as to avoid glue leakage and polluting the equipment and environment. The max. speed of plane processing is 12m / min.

520D配置表
